ITEM
MODEL KGX
 10 16 25 40 63 80 100 125 160 200 250 315 400
    A B C D A B C D A B C D A B C D A B C D A B C D A B C D A B A B A B A B A B A
Force kn 100 160 250 400 630 800 1000 1250 1600 2000 2500 315 4000
Rated distance before BDC mm 2 1.6 3.15 2.2 3.5 2.2 4 2.2 5 2.5 5 2.5 5 2.5 5 6.3 6.3 7 6.3 8 8 10 12
Stroke Length mm 50 8-50 50 8-50 63 8-63 80 8-80 80 8-80 80 8-80 88 8-88 88 8-88 100 8-100 100 8-100 112 8-112 112 8-112 125 8-125 125 8-125 160 8-160 160 8-160 200 20-16 200 20-160 200 20-130 250
Number of Stroke min-1 75 150 75 150 70 140 65 130 60 120 56 110 45 125 40 40 40 35 35 20
Fly-Wheel Energy kj 1.0 0.7 2.5 1.5 4.4 3.0 8.0 4.6 16.75 7.78 20.0 10.0 25.0 12.0 32.0 55.0 70.0 80.0 120.0 240.0
Throat Depth mm 165 185 210 235 285 325 325 365 365 410 410 510 510
Shut Height Over Bed(Stroke DownAdj.Up) mm 200 265 300 315 350 450 450 500 500 560 560 630 700
Slide Adjustment mm 50 50 63 70 70 80 80 125 125 125 125 125 125
Slide Area (L - R x F - B) mm 225 x 160 280 x 170 350 x 250 400 x 350 500 x 400 550 x 450 600 x 450 710x600 710x600 900x800 900x800 1200x800 1200x800
Bolster Area (L - R x F - B) mm 540 x 315 600 x 355 630 x 400 800 x 450 900 x 550 1000 x 630 1000 x 630 1120x750 1250x800 1250x800 1450x900 1450x900 1200x800
Bolster Thickness mm 65 70 75 75 90 90 90 112 120 150 150 150 175
Bed Opening (L - R x F - B) mm 220 x 160 280 x 200 315 x 224 355 x 250 400 x 280 450 x 315 500 x 355 560x400 560x450 630x450 600x500 900x560 900x560
Clear Distance Between Uprights mm 330 375 420 500 590 620 670 670 775 900 -- -- --
Main Motor kwxrpm 1.1x1500 1.1x1000 1.5x1500 1.5x100 2.2x1500 2.2x1000 3.7x15003.7x100 5.5x1500 5.5x1000 5.5x1500 5.5x1000 7.5x1500 7.5x1000 11x1500 15x1500 15x1500 18.5x1500 22x1500 30x1500
Slide Adjustment Motor kwxrpm -- -- -- -- -- -- -- 1.1x3000 1.1x1500 1.1x1500 1.5x1000 1.5x1000 2.2x100
Height From Roor to Top of Bolster mm 800 800 800 900 900 900 900 900 900 900 900 900 900
Machine Weight (Approx) kg. 950 900 1750 1600 2250 2100 3850 3600 6100 5600 6800 6300 9000 8500 12000 17000 2000 28000 34000 34000
Required Air Pressure atm 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5
Model -- -- DC-72 DC-72 DDC-82 DDC-102 DDC-123 DDC-123 DDC-143 3DC-144 3DC-164 3DC-164 DC-002-30-125
Force kn -- 17 17 44 70 100 100 135 200 200 270 300
Strock Length mm -- 50 50 50 50 75 75 75 100 100 100 100
Pressure Pad Area mm -- 260x180 290x200 335x230 380x260 430x290 475x330 535x375 535x425 600x425 600x475 850x520
Required Air Pressure atm -- 7 7 7 7 7 7 7 7 7 7 5
Note: Available on requirement.
ITEM MODEL KGX-80 10 16 25 40 63 80/100 125 160 200/250 315 400
1'N'Width (L-R) 540 600 630 800 600 1000 1120 1120 1250 1450 1450
'0' Depth (F-13) 315 355 400 450 550 630 710 750 800 900 900
'F' Thickness 65 70 75 75 90 90 112 120 150 150 175
'S' Teel Slot Width 18 18 18 22 22 28 28 28 28 28 28
'M' Teel Slot Pitch 115 130 150 170 190 200 225 150 150 * *
'H' -- -- -- -- -- -- -- 280 325 * *
'P' -- -- -- -- -- -- -- 130 150 * *
Q' Opening With Ring 70 70 70 90 90 90 90 175 200 -- --
'R' Opening Without Ring 150 180 200 225 280 315 315 350 375 -- --

ITEM MODEL KGX-80 10 16 25 40 63 80 100 125/160 200/250 315/400
'W'Width (L-R) 225 280 350 400 500 550 600 710 900 1200
XDepth (F-13) 160 170 250 350 400 450 450 600 800 800
'S' Teel Slot Width x No. of Teel Slots 18x1 18x1 18x1 22x1 22x1 28x1 28x2 28x2 28x4 28x6
'J' Teel Slots Pitch 150 150 180 180 220 280 200 225 150 150
Z x Y Shank Hole Dia x Depth 32x50 40x70 40x75 50x85 50x85 63x85 63x85 63x105 80x110 80x110
Note: As day to day improvements are contemplated we reserve the right to change specification/design without prior notice.
